ETL1310 Certificate 12V 1A Power Adapter Wall Mounted AC For LED

  • 1
  • 2
  • 3

Brand Name : Analog

Model Number : GQ15-120100-AG

Certification : ETL1310/IEC61347

Place of Origin : China

MOQ : 1000

Price : Negotiable

Payment Terms : T/T

Supply Ability : 1,600,000~1,800,000PCS/Month

Delivery Time : 10-25 work days

Packaging Details : White box+Carton

Certificate : CE/LVD/EMC/EN61558/EN61347

Input : 90VAC~264VAC,47~63HZ

Output : 12W,12V,DC1A

Protection : OVP,OCP,OTP,SCP & Input Protection

Material : PC plastic shell+Copper Cord+Copper Pins

Warranty : 24 Months

Contact Now

ETL1310 Certificate 12V 1A Power Adapter Wall Mount AC Adapter With EU Plug for LED



What kind of adapter do I need for LED lights?

Mostly will need a 12V power supply for LED lights

12V power adapter is widely used in lighting field, especially desk lamp.

It is generally composed of shells, transformers, inductors, capacitors, control ICs, PCB boards and other components.

Its working principle is converted from AC input to DC Output.



Application:Indoor lighting products



Product Highlights:

                                 ★ 94V-0 PC shell, 750℃ Glow WireTest bearable and environment friendly;

                                ★ Product temperature below industry standard,more safety and longer lifetime;

                               ★ Multiple DC connector could be customized,more choice for your products;




Specification Datasheet Table



15W series
  Output Voltage 12V
Output Current 1A
Output Power 12W
Input Voltage & Frequency 90VAC~264VAC, 47~63HZ
Maximum AC Current Please refer to the specification datasheet for approval
Input Inrush Current 40A(RMS) Max, full load tested @AC230V 50HZ
Efficiency VI
Protection OVP,OCP,OTP,SCP & Input Protection
Environmental requirements Operating Temperature 0~40 ℃,
Storage Temperature -40~70 ℃
Operating Humidity 5%~90% Non-condensing
Storage Humidity 5%~90% Non-condensing
Reliability Warranty 2 year (about 2.28 years for 24-hour-operation a day)
MTBF >20,000 hour
Insulation Resistanc > 30MΩ@500VDC; 60S
Hi-Pot Meet different safety standard
Leakage Current 0.25mA Max, full load tested @AC230V 50HZ
Compliance with EU directives law & regulations RoHS,REACH,PAHS
Safety Standard Certificate UL/ETL/FCC/CE/ GS/UKCA/ PSE/ KC/ SAA/ EAC/BIS/ICBR/CCC
Standards ETL1310, IEC61347,GB4706,K60950
EMC EN55014-1/EN55014-2 compliance
ESD (Air discharge@ 8KV, Contact discharge@ 6KV,(IEC61000-4-2)
Surge ±1KV @ common or different mode



ETL1310 Certificate 12V 1A Power Adapter Wall Mounted AC For LED




ETL1310 Certificate 12V 1A Power Adapter Wall Mounted AC For LED
